Features :

• Standard nickel-plated brass material for superior corrosion resistance.

• Neoprene seal certified from -30˚C to +80˚C.

• Available with silicone seal certified from -60˚C to +140˚C.

• Suitable for Cold Flow cable.

• Armour clamping and bonding with no reversible components for easy

installation, minimizing error.

• Related accessories, see pages D.12 to D.15

Caution: A cable clamping must be realized within a range of 300 mm from the

extremity of the cable gland.

Certifications and Compliances

• ATEX II 2 GD – Exd IIC/Exe II/ExtD

• IECEx Exd IIC/Exe II/ExtD

• cULus Listed for Class I Zone 2 AEx e II/

Ex e II

• cULus Marine Listed for Class I Zone 1

AEx II/Ex e II

• NEMA 4X, IP68

• CEPEL

• NEPSI GB

• DNV

• ABS approbation

• Lloyds

• ADE 4F-Series Ex Cable Gland
