Features:
• Standard nickel-plated brass material for superior corrosion resistance.
• TSC compound certified from -60˚C to +80˚C.
• Provides flameproof seal on the wires and the inner sheath of the
armoured cables.
• Provides the sealing on the outer sheath of the armoured cables.
• Red cap nut: “compound inside”.
• Deluge boot provides enhanced protection from water ingress.
• Fully inspectable sealing and armour clamping and crimping including
deluge boot.
• Armour clamping and bonding with no reversible components for easy
installation, minimizing error.
• Related accessories, see pages D.12 to D.15
Caution: A cable clamping must be realized within a range of 300 mm from the
extremity of the cable gland.
